電動卷簾門做為現下運用較廣的門類其一，被眾多大型、加工廠、家居喜愛。卷簾門內部構造具體可分為電機部分、簾片部分和別的的卷簾門配件，接下來分別因其內部結構圖來詳解一下卷簾門的不同構成部分和運作方式。

As one of the widely used categories, electric roller shutter doors are loved by many large shopping malls, processing plants and home furnishings. The internal structure of roller shutter door can be specifically divided into motor part, curtain part and other accessories of roller shutter door. Next, the different components and operation modes of roller shutter door will be explained in detail according to its internal structure diagram.

電動卷簾門整體結構：

Overall structure of electric roller shutter door:

(1)固定結構：導軌（不銹鋼或者鋁合金）、端蓋板、不銹鋼包廂；

(1) Fixed structure: guide rail (stainless steel or aluminum alloy), end cover plate, stainless steel box;

(2)防護結構：門簾、地梁、地梁膠條、端卡；

(2) Protective structure: door curtain, ground beam, ground beam rubber strip, end clamp;

(3)驅動結構：電機、卷軸、電機皇冠輪、電機驅動輪；

(3) Drive structure: motor, reel, motor crown wheel, motor drive wheel;

(4)其他：毛刷，五金配件。

(4) Others: brush, hardware accessories.

電機結構圖:

Motor structure diagram:

電機由電動機、減速箱 、自動限位器 、制動機械 、電器盒 、手動機械 、手動拉鏈 、大齒輪 、按鈕開關和安裝鐵板構成。

The motor is composed of motor, reducer, automatic limiter, braking machinery, electrical box, manual machinery, manual zipper, big gear, button switch and installation iron plate.

相關配件：

Related accessories:

(1)77#封頭、65#封頭、55#封頭、50#封頭、37#封頭

(1) 77# head, 65# head, 55# head, 50# head, 37# head

(2)簾片底膠條

(2) Curtain bottom rubber strip

(3)普通手搖桿

(3) Ordinary hand rocker

(4)過墻桿離合鎖

(4) Wall bar clutch lock

(5)開關盒

(5) Switch box

(6)過墻手搖桿

(6) Wall rocker

(7)手動扭簧

(7) Manual torsion spring

(8)專用彈簧

(8) Special spring

電動卷簾門運作方式:

Operation mode of electric roller shutter door:

電機隱蔽于卷管內，借助電機運轉拉動傳動軸運轉，達到卷簾簾片的升縮，升高簾片卷繞在卷軸上，降低簾片沿著滑軌里側滑下來。借助控制器的操縱來達到窗簾的升高、停下、降低動作。另有帶跳閘手動式釋放出來系統，在跳閘的狀況下可借助手動式搖桿使卷簾門升縮。

The motor is hidden in the rolling pipe, and the driving shaft is pulled to operate with the help of the motor operation, so as to achieve the rise and contraction of the rolling curtain sheet, raise the curtain sheet and wind it on the rolling shaft, and lower the curtain sheet to slide down along the side of the slide rail. With the help of the control of the controller, the curtain can be raised, stopped and lowered. In addition, there is a manual release system with tripping. In the case of tripping, the roller shutter door can be raised and retracted with the help of a manual rocker.

濟南電動卷簾門的安裝要先在設置門框處做標記，再量出門洞的規格大小，根據規格制作符合標準的電動卷簾門，然后把門框固定好并在兩邊提前留下凹槽，等到調整合格之后，再固定上木楔，之后通過水泥砂漿加固，接著裝上電動卷簾門，保證它和墻體變成一體，盡量保證無縫隙，這樣能夠方便使用。

The installation of Jinan electric roller shutter door should first make a mark at the place where the door frame is set, then measure the size of the door opening, make the electric roller shutter door that meets the standard according to the specification, then fix the door frame and leave grooves on both sides in advance, wait until the adjustment is qualified, then fix the wooden wedge, and then reinforce it with cement mortar, and then install the electric roller shutter door to ensure that it is integrated with the wall and that there is no gap as far as possible, This makes it easy to use.
